Trend Router T5EK MK2

Trend router T5EK MK2

A router based on the time-honoured ELU MOF96, with modern adaptations. Compact and handy for all common types of routing.

Technical Data

• Input power: 1,000 W
• Voltage: 230 V
• Collet Ø: 8 mm
• Stroke: 50 mm
• Speed: 9,000 - 27,000 rpm (electronically adjustable)
• Rip fence guides: M-M: 84 mm | Ø: 8 mm
• Cutter Ø, max.: 40 mm
• Inner Ø, suction nozzle: 35 mm
• Sound level: 72 dB (Lpa) | 92 dB (Lwa)
• Weight: 3.3 kg
• Cable: 2.9 m
• Base plate: Ø: 150 mm | ll: 110 mm
• EU plug

Features and advantages

• Small and very handy for maximum convenience in manual operation.
• Electronic speed control and soft start for perfect control.
• On/off switch WITHOUT locking function (restart protection).
• Can be used for rounding, bevelling, profiling and rebating, grooving, engraving and template work.
• Approved for router bits with a max. diameter of 40 mm.
• Very precise rip fence with micro-fine adjustment for precise adjustability.
• Circles can be milled in next to no time with the included compass attachment.

Scope of delivery

• 1x Trend T5EK MK2 EURO router
• 1x Fence with fine adjustment
• 1x Extraction nozzle
• 1x cCopy sleeve, Ø20mm
• 1x Compass attachment
• 1x Spanner for union nut
