Harvey ALPHA HW110SE-36T table saw

Harvey ALPHA HW110SE-36T table saw

We believe that the ALPHA HW110SE range of circular saws offers the ultimate solution to the problem of corrosion. Guided by our unwavering philosophy that "Good Enough is Not Enough", these saws are an example of our unwavering commitment to innovation and precision. At the heart of its ground-breaking functionality is the innovative Big Eye cutting fence system, which has already revolutionised precision and ease of use in woodworking.

General information on the HW110SE series:

The circular table saws of the HW110SE-36(T)/52(T) series are the engineered proof of performance and precision, combined with safety.

Depending on the model, the machines are equipped with powerful 2.2 kW or 4 kW spindle motors. All models in the series are equipped with an MG-36 Pro M "COMPASS" mitre fence for precise, 11 commonly detented or infinitely adjustable angles for the production of mitre cuts and angle divisions.

The special, transparent saw blade guard for controlled, aerodynamic dust removal is also included in the scope of delivery.

The complete ALPHA series HW110SE-36(T)/52(T) is manufactured to the highest technological quality standards. The HW 110 series is not just about machine tools, but about innovations for your trade. Regardless of whether you are a hobby craftsman or an experienced professional setting up a woodworking shop. These saws offer you the reliability and performance you need to take your woodworking projects to the next level.

Technical Data

• Product dimensions:
  • Weight: 262kg
  • Länge/Breite/Höhe: 1760x1050x1220mm
  • Stand - dimensions: 533x560mm
• Switches:
  • Switch type: Magnetic with thermal overload protection
  • Norm/Standard: UL62841
• Motor:
  • Type: Three-phase asynchronous
  • Performance data, electrical connection values, 50-60Hz: 4kw; 5.5PS; 3Ph; 8.3A; 400V
  • Motor speed n1 (min^-1): 2850
  • Power transmission: Ribbed belt transmission i=0.72
• Information on cutting geometry:
  • Nominal saw blade diameter: D 250mm
  • Riving knife width: 2.5mm
  • Max. groove width: 20.3mm
  • Saw blade inclination (°): 0.45°; to the left
  • Spindle diameter on saw blade: D 30mm
  • Spindle speed n2 (min^-1): 4000
  • Spindle bearing: 2RS, maintenance-free, lubricated for life
• Cutting capacities:
  • Maximum cutting depth at 90°/D250: 70mm
  • Maximum cutting depth at 45°/D250: 50mm
  • Maximum stop cutting width, right: 915mm
  • Maximum fence cutting width, left: 228mm
• Table dimensions:
  • Main table dimensions: 800x1120x46.5mm
  • Table height: 860mm
  • Table groove type and dimensions: T-shape 1"; 3/4"; 3/8" (25.4; 19.05; 9.52mm)
  • Mitre fence dimensions: 22"; 560mm; 0-+-60°
  • Saw blade cover/hood: CE version saw blade cover
• Profile fence:
  • Profile fence dimensions: 87x50mm
  • Dust exhaust air connection D: 4"; 100mm
• Other product information:
  • Surface: nickel-plated table, powder-coated housing

This product is certified by TÜV Rheinland.

Features and advantages

• Precision cutting table made of nickel-plated cast iron, vibration-absorbing and corrosion-resistant
• Innovatively designed, precise BIG EYE cutting stop system
• DESTROYER universal saw blade, manufactured to industry standards
• MG-36 Pro "COMPASS" mitre and angle fence
• Powerful 4 kW TEFC motor
• The versatile fence positions
• Unique, dovetail-shaped, nickel-plated pivot pin system
• Dust collector with suction connection underneath the saw blade
• Specially moulded, transparent upper saw blade guard for visual monitoring of aerodynamically perfect dust removal
• Built-in dust collection hose system
• Magnetic safety switch

Scope of delivery

• 1x Harvey ALPHA HW110SE-36T table saw (incl. Big Eye cutting fence system and MG-36PRO mitre fence)
